24375-04000 Oil Control Variable Valve Timing VVT Solenoid for Hyundai i10/2010-2011 KiaPicanto/2011 Morning/2011 High quality

Description

24375-04000 Oil Control Valve (VVT Solenoid) is a premium OEM-grade component specifically designed for Hyundai/Kia’s 1.1L-1.2L Kappa engines in compact models. Here’s the professional technical breakdown:

✅ Confirmed Vehicle Compatibility

✔ Hyundai i10 (2010-2011) – 1.1L/1.2L Kappa (G4LA/G4LC)
✔ Kia Picanto (2011+) – 1.0L/1.2L (G4LA/G4LC)
✔ Kia Morning (2011+) – 1.0L/1.2L (G4LA/G4LC)

*Note: Later models (2012+) may require updated part numbers*

🔧 Technical Specifications

• OEM Part Number: 24375-04000

• Engine Applications:

  • 1.0L Kappa (G4LC)

  • 1.1L/1.2L Kappa (G4LA)

• Voltage: 12V PWM-controlled

• Flow Rate: 1.5 L/min @ 30 psi

• Response Time: <150ms

• Connector: Sumitomo TS-030 (2-pin waterproof)

• Mounting Torque: 4.0-5.0 Nm (35-44 in-lbs)

⚠️ Failure Symptoms

• Diagnostic Trouble Codes:
  ▸ P0010 (VVT Circuit Malfunction)
  ▸ P0011 (Intake Cam Over-Advanced)
  ▸ P0012 (Intake Cam Over-Retarded)

• Operational Issues:
  ▸ Extended cranking on cold starts
  ▸ Irregular idle (700-900 RPM fluctuation)
  ▸ 15-20% fuel economy degradation
  ▸ Loss of low-end torque

🔧 Expert Installation Guide

1. Location:

   • Front timing cover (driver’s side)

   • Behind accessory drive belt

2. Special Tools Required:

   • 10mm micro ratchet

   • O-ring removal hook (OTC 4565)

   • Inch-pound torque wrench

3. Critical Installation Steps:

   • Degrease mounting surface with IPA

   • Lubricate new O-ring with silicone grease

   • Hand-start bolt before final torquing

   • Perform ECU reset via OBD-II scanner
